IPv6 RIPEness: Production & Updates

Vesna Manojlovic
Contributors: Emile Aben, Inigo Ortiz de Urbina, Rene Wilhelm

4 min read

0 You have liked this article 0 times.

Following your feedback, we decided to make IPv6 RIPEness a production service. We are currently working on some new features. Stay tuned!

In the previous article IPv6 RIPEness - One Year Later, I asked several questions about additional features and criteria and the future of this service. Thanks to your support on the RIPE NCC members-discuss mailing list and on RIPE Labs itself, we are now moving IPv6 RIPEness to production service! We did not make any significant changes to the service yet, but there is a progress. See below some examples.

To visualise the IPv6 RIPEness in our service region, we are working on a way to show IPv6 RIPEness per country on a map. Please see a below a quick-and-dirty first attempt, using Google Chart Tools (Thanks, Emile & Iñigo!). To make coding easy, we presented the percentages of four-star Local Internet Registries (LIRs) per country on a gradient scale, from red to green, comparable to a traffic-light (rather than the "ripe fruit" colouring scheme used earlier). In the image below, this means: countries with the highest number of four-star LIRs are marked in green, countries with the lowest number of four-star LIRs are marked red. Keeping this in mind, you can see that the following countries are leading: Portugal, Moldova, Armenia, The Netherlands and Slovenia.

Map of IPv6 RIPEness Oct 2011

Figure 1: Map showing IPv6 RIPEness in the RIPE NCC service region(green = country with highest number of four-star IPv6 RIPEness; red= countries with lowest number of four-star LIRs)

Since the initial purpose of the IPv6 RIPEness rating was to determine which country needs more attention and training, we analysed the impact RIPE NCC IPv6 training courses have on the IPv6 RIPEness in a country. The most stunning example was Armenia: In March 2011 the RIPE NCC organied an IPv6 course there. Within 3 weeks after the course there was a 20% increase in the number of IPv6 allocations! And even now, Armenia has the 2nd highest total RIPEness score in the RIPE NCC service region: (74% of all LIRs in Armenia have one-to-four stars vs. 26% that have zero stars), just after Slovenia (78% vs. 22%), and just before Romania (73% vs. 27%) & Portugal (71% vs. 29%).

My colleagues Emile Aben & Marco Hogewoning are currently researching the impact of events (such as courses or conferences ) on the IPv6 deployment so more. The findings will be presented at RIPE63 in Vienna.

The relative ratings are obviously biased towards countries with a small number of LIRs. The graph below shows the absolute values for IPv6 RIPEness in the 15 countries with the largest number of LIRs.

IPv6 RIPEness Top-15 Oct 2011 Figue 2: IPv6 RIPEness in the 15 countries with the highest number of LIRs

The total number of LIRs with IPv6 address space did not reach 50%, as some people were hoping. As shown in the image below, 54% of all LIRs with still has zero stars which means they don't have an IPv6 allocation.  One of the possible reasons is the sharp growth in the number of new LIRs: since the last IPv6 RIPEness count in May 2011, there were 390 more LIRs; the number of LIRs requesting IPv6 space was bigger (516 LIRs) - but percentage wise, we are still “transitioning” slowly.

IPv6 RIPEness pie-chart Oct 2011 Figure 3: Percentage of LIRs with one to four stars as measured end on 25 October 2011

I am also working with other RIRs on a global IPv6 RIPEess rating – stay tuned!
