## Flip-flops

## Introduction

You covered about latches in the previous modules. Those are the basic building blocks of flip-flops. You can implement flip-flops in two methods.

In first method, cascade two latches in such a way that the first latch is enabled for every positive clock pulse and second latch is enabled for every negative clock pulse. So that the combination of these two latches become a flip-flop.

In second module, you can directly implement the flip-flop, which is edge sensitive. In this module, let us discuss the following flip-flops using second method.

## Differences between latches and flip-flops

Latches | Flip-flops |
---|---|

Level triggered | Edge triggered |

Asynchronous device | Synchronous device |

Doesn’t contain clock signal | Contains a clock signal |

It will change its state as long as it is enabled | It will change its state only during a given clock cycle |

Consumes less power | Consumes more power |

Faster | Slower |

Examples: D-Latch, T-Latch | Examples: D-Flip flop, T-Flop flop |

## Sub-modules

Now let us implement various flip-flops by providing the cross coupling between NOR gates. You can also implement these flip-flops by using NAND gates, as well.

## SR flip-flop

## Introduction

SR flip-flop operates with only positive clock transitions or negative clock transitions. Whereas, SR latch operates with enable signal. The circuit diagram of SR flip-flop is shown in the following figure.

his circuit has two inputs S & R and two outputs Q(t) & Q(t)’. The operation of SR flipflop is similar to SR Latch. But, this flip-flop affects the outputs only when positive transition of the clock signal is applied instead of active enable.

## State table

S | R | Q(t+1) |
---|---|---|

0 | 0 | Q(t) |

0 | 1 | 0 |

1 | 0 | 1 |

1 | 1 | - |

Here, Q(t) & Q(t + 1) are present state & next state respectively. So, SR flip-flop can be used for one of these three functions such as Hold, Reset & Set based on the input conditions, when positive transition of clock signal is applied.

## Characteristic table

Therefore, SR Latch performs three types of functions such as Hold, Set & Reset based on the input conditions.

S | R | Q(t) | Q(t+1) |
---|---|---|---|

0 | 0 | 0 | 0 |

0 | 0 | 1 | 1 |

0 | 1 | 0 | 0 |

0 | 1 | 1 | 0 |

1 | 0 | 0 | 1 |

1 | 0 | 1 | 1 |

1 | 1 | 0 | x |

1 | 1 | 1 | x |

By using three **variable K-Map**, you can get the simplified expression for next state, Q(t + 1). The three variable K-Map for next state, Q(t + 1) is shown in the following figure.

The maximum possible groupings of adjacent ones are already shown in the figure. Therefore, the simplified expression for next state Q(t + 1) is

```
Q(t + 1) = S + R'.Q(t)
```

## D flip-flop

## Introduction

D flip-flop operates with only positive clock transitions or negative clock transitions. Whereas, D latch operates with enable signal. That means, the output of D flip-flop is insensitive to the changes in the input, D except for active transition of the clock signal. The circuit diagram of D flip-flop is shown in the following figure.

This circuit has single input D and two outputs Q(t) & Q(t)’. The operation of D flip-flop is similar to D Latch. But, this flip-flop affects the outputs only when positive transition of the clock signal is applied instead of active enable.

## State table

D | Q(t+1) |
---|---|

0 | 0 |

1 | 1 |

Therefore, D flip-flop always Hold the information, which is available on data input, D of earlier positive transition of clock signal. From the above state table, the next state equation can be directly written as

```
Q(t + 1) = D
```

Next state of D flip-flop is always equal to data input, D for every positive transition of the clock signal. Hence, D flip-flops can be used in registers, shift registers and some of the counters.

## JK flip-flop

## Introduction

JK flip-flop is the modified version of SR flip-flop. It operates with only positive clock transitions or negative clock transitions. The circuit diagram of JK flip-flop is shown in the following figure.

This circuit has two inputs J & K and two outputs Q(t) & Q(t)’. The operation of JK flip-flop is similar to SR flip-flop. Here, the inputs of SR flip-flop are considered as **S = J Q(t)’** and **R = KQ(t)** in order to utilize the modified SR flip-flop for 4 combinations of inputs.

## State table

J | K | Q(t+1) |
---|---|---|

0 | 0 | Q(t) |

0 | 1 | 0 |

1 | 0 | 1 |

1 | 1 | Q(t)’ |

Here, Q(t) & Q(t + 1) are present state & next state respectively. So, JK flip-flop can be used for one of these four functions such as Hold, Reset, Set & Complement of present state based on the input conditions, when positive transition of clock signal is applied.

## Characteristic table

J | K | Q(t) | Q(t+1) |
---|---|---|---|

0 | 0 | 0 | 0 |

0 | 0 | 1 | 1 |

0 | 1 | 0 | 0 |

0 | 1 | 1 | 0 |

1 | 0 | 0 | 1 |

1 | 0 | 1 | 1 |

1 | 1 | 0 | 1 |

1 | 1 | 1 | 0 |

By using three variable K-Map, you can get the simplified expression for next state, Q(t + 1). The **three variable K-Map** for next state, Q(t + 1) is shown in the following figure.

The maximum possible groupings of adjacent ones are already shown in the figure. Therefore, the simplified expression for next state Q(t+1) is

```
Q(t + 1) = J.Q(t)' + K'.Q(t)
```

## T flip-flop

## Introduction

T flip-flop is the simplified version of JK flip-flop. It is obtained by connecting the same input ‘T’ to both inputs of JK flip-flop. It operates with only positive clock transitions or negative clock transitions. The circuit diagram of T flip-flop is shown in the following figure.

This circuit has single input T and two outputs Q(t) & Q(t)’. The operation of T flip-flop is same as that of JK flip-flop. Here, the inputs of JK flip-flop are considered as J = T and K = T in order to utilize the modified JK flip-flop for 2 combinations of inputs. So, the other two combinations of J & K are eliminated, for which those two values are complement to each other in T flip-flop.

## State table

D | Q(t+1) |
---|---|

0 | Q(t) |

1 | Q(t)’ |

Here, Q(t) & Q(t + 1) are present state & next state respectively. So, T flip-flop can be used for one of these two functions such as Hold, & Complement of present state based on the input conditions, when positive transition of clock signal is applied.

## Characteristic table

T | Q(t) | Q(t + 1) |
---|---|---|

0 | 0 | 0 |

0 | 1 | 1 |

1 | 0 | 1 |

1 | 1 | 0 |

From the above characteristic table, the next state equation can be directly written as:

```
Q(t + 1) = T'.Q(t) + T.Q(t)'
=> Q(t + 1) = T ⊕ Q(t)
```

The output of T flip-flop always toggles for every positive transition of the clock signal, when input T remains at logic High (1). Hence, T flip-flop can be used in counters.

## Master-slave JK flip-Flop

## Introduction

Master-slave JK flip-flop is designed to eliminate the race around condition in JK flip-flop and it is constructed by using two JK flip-flops as shown in the circuit diagram below.

The first flip-flop is called the *master*, and it is driven by the positive clock cycle.
The second flip-flop is called the *slave*, and it is driven by the negative clock cycle.
During the positive clock cycle, master flip-flop gives the intermediate output but slave flip-flop will not give the final output.
During the negative clock cycle, slave flip-flop gets activated and copies the previous output of the master flip-flop and produces the final output.

## Master-slave JK flip-flop constructed by using NAND gates

## State table

Clock | J | K | Q(n+1) | Comments |
---|---|---|---|---|

0 | X | X | Q(n) | No change |

1 | 0 | 0 | Q(n) | No change |

1 | 0 | 1 | 0 | Reset |

1 | 1 | 0 | 1 | Set |

1 | 1 | 1 | Q(n)’ | Toggle |

Here, Q(n) is the present state and Q(n+1) is the next state.

## Characteristic table

Q(n) | J | K | Q(n+1) |
---|---|---|---|

0 | 0 | 0 | 0 |

0 | 0 | 1 | 0 |

0 | 1 | 0 | 1 |

0 | 1 | 1 | 1 |

1 | 0 | 0 | 1 |

1 | 0 | 1 | 0 |

1 | 1 | 0 | 1 |

1 | 1 | 1 | 0 |

## Excitation table

Q(n) | Q(n+1) | J | K |
---|---|---|---|

0 | 0 | 0 | X |

0 | 1 | 1 | X |

1 | 0 | X | 1 |

1 | 1 | X | 0 |

## Characteristic equation

```
Q(n+1) = Q(n)'J + Q(n)K'
```

## Differences between SR and JK flip-flop

JK Flip-flop | SR Flip-flop |
---|---|

When J input is 1 and K input is 0 on the triggering edge of clock pulse,then output is in set state | When S input is 1 and R input is 0,output is in set state |

When J input is 0 and K input is 1 on the triggering edge of clock pulse,then the output is in reset state | When S input is 0 and R input is 1,output is in reset state |

When J and K input both are 1 on the triggering edge of clock pulse,then the output toggle wrt what was the state in the previous clock cycle | When both S and R input are 0,there is no change in output and it holds the previous state |

There are no invalid states even if both ‘J’ and ‘K’ flip flops are set to 1 | When both inputs are set to 1, the circuit produces the invalid states as outputs |

## Differences between T and D flip-flop

T Flip-flop | D Flip-flop |
---|---|

Single input version of JK flip-flops | Single input version of SR flip-flops |

When the clock rises from 0 to 1, the value remembered by the flip-flop either toggles or remains the same depending on whether the T input (Toggle) is 1 or 0 | When the clock rises from 0 to 1, the value remembered by the flip-flop becomes the value of the D input (Data) at that instant |

It has an input and an output and will toggle no matter what | It has an input, an output, and a clock , and will only change its output when the clock is on |

## Flip-flops interaction

# State Table Generator

"A *State Table* is a tabular representation of the time
sequence of inputs, outputs, and flip-flop states. The table
consists of four sections marked as *present table*,
*next state*, and the *output*. The present-state section
shows the states of flip-flops at any given time t. The input
section gives a value for each possible present state. The
next-state section lists the state of flip-flops one clock period
later at time t + 1. Lastly, the output section gives the value for
each present state."

**STEP 1.**Provide the following.

**STEP 2.**Input the required flip-flop input/output functions.

Feel free to review your input before generating your state table.
